| Nomor Bagian | LTL097QL01-A01 |
| Merek | Samsung |
| Ukuran | 9.7 |
| Aplikasi | PAD |
| Resolusi | 2048×1536 |
| Komposisi | LCM |
| Kecerahan | 420 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | SAMSUNG |
| model panel | LTL097QL01-A01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 9.7 inch |
| resolusi | 2048(RGB)×1536 , QXGA |
| mode tampilan | PLS, Normally Black, Transmissive |
| daerah aktif | 196.608×147.456 mm |
| permukaan | |
| kecerahan | 420 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit) |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLED |
| antarmuka sinyal | eDP (4 Lanes) |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
