| Nomor Bagian | HSD101PUW1-A00 |
| Merek | HannStar |
| Ukuran | 10.1 |
| Aplikasi | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 380 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | HannStar |
| model panel | HSD101PUW1-A00 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.1 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mode tampilan | HS-IPS, Normally Black, Transmissive |
| daerah aktif | 216.576×135.36 mm |
| garis besar | 227.72×147.8×4.55 mm |
| permukaan | Hard coating |
| kecerahan | 380 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC), CIE193150% |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | MIPI (4 data lanes), 34 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
