| Nomor Bagian | VVX07H005A00 |
| Merek | Panasonic |
| Ukuran | 7.0 |
| Aplikasi | PAD |
| Resolusi | 800×1280 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | Panasonic |
| model panel | VVX07H005A00 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800(RGB)×1280 , WXGA |
| mode tampilan | IPS, Normally Black, Transmissive |
| daerah aktif | 94.2×150.72 mm |
| garis besar | 104.32×161.67×3.8 mm |
| permukaan | Hard coating |
| kecerahan | 450 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 30 (Max.)(Tr+Td) |
| sudut pandang | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 5S5PWLEDWithout Driver |
| antarmuka sinyal | MIPI (4 data lanes), 34 pins |
| tegangan masukan | 1.8/3.3V (Typ.)(VCC/VDD) |
| aplikasi | PAD |
