| Nomor Bagian | LQ097L1JY02Z |
| Merek | SHARP |
| Ukuran | 9.7 |
| Aplikasi | PAD |
| Resolusi | 2048×1536 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | SHARP |
| model panel | LQ097L1JY02Z |
| tipe panel | IGZO TFT-LCD , LCM |
| ukuran panel | 9.7 inch |
| resolusi | 2048(RGB)×1536 , QXGA |
| mode tampilan | Normally Black, Transmissive |
| daerah aktif | 196.608×147.456 mm |
| permukaan | |
| kecerahan | |
| rasio kontras | |
| menampilkan warna | 16.7M (8-bit) |
| waktu merespon | |
| sudut pandang | |
| frekuensi | 60Hz |
| jenis lampu | WLED |
| antarmuka sinyal | eDP (4 Lanes) |
| aplikasi | PAD |
