B101UAN01.7 HW1A

B101UAN01.7 HW1A
B101UAN01.7 HW1A
B101UAN01.7 HW1A
B101UAN01.7 HW1A thumb B101UAN01.7 HW1A thumb B101UAN01.7 HW1A thumb
Merek
AUO
Ukuran
10.1
Aplikasi
PAD
Resolusi
1920×1200
Komposisi
LCM
Kecerahan
380
CR
800:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
MIPI
In Stock
6000
Spesifikasi

Nomor Bagian B101UAN01.7 HW1A
MerekAUO
Ukuran10.1
AplikasiPAD
Resolusi1920×1200
KomposisiLCM
Kecerahan380
CR800:1
Warna16.7M
Lampu latarWLED
AntarmukaMIPI
merek panelAUO
model panelB101UAN01.7 HW1A
tipe panel a-Si TFT-LCD , LCM
ukuran panel10.1 inch
resolusi1920(RGB)×1200 , WUXGA
mode tampilanAHVA, Normally Black, Transmissive
daerah aktif216.81×135.5 mm
garis besar227.72×147.8×5.35 mm
permukaanGlare (Haze 0%)
kecerahan380 cd/m² (Typ.)
rasio kontras800:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193150%
waktu merespon25 (Typ.)(Tr+Td)
sudut pandang85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyalMIPI (4 data lanes), 34 pins
tegangan masukan3.7V (Typ.)
aplikasiPAD
Model Keluarga
B101UAN01.1 AUO 10.1 1920×1200
B101UAN01.7 HW0A AUO 10.1 1920×1200
B101UAN01.7 HW1A AUO 10.1 1920×1200
B101UAN01.7 HW2A AUO 10.1 1920×1200
B101UAN01.9 AUO 10.1 1920×1200
B101UAN01.C AUO 10.1 1920×1200
B101UAN01.E AUO 10.1 1920×1200
B101UAN02.1 AUO 10.1 1920×1200
B101UAN07.0 AUO 10.1 1200×1920
B101UAN07.2 AUO 10.1 1200×1920
