| Nomor Bagian | GV101WXB-NZ1-DGP0 |
| Merek | BOE |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1280×800 |
| Komposisi | CELL, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| pabrikan | BOE |
| nama model | GV101WXB-NZ1-DGP0 |
| ukuran layar | 10.1 inch |
| tipe layar | CELL, a-Si TFT-LCD |
| nomor piksel | 1280(RGB)×800 (WXGA) 149PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 216.96 × 135.6 (H×V) |
| garis besar (mm) | 221.96 × 144.43 × 1.06 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Without Polarizer, Hard coating |
| pencahayaan | 0 cd/m² |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tanggapan | 35 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | No B/L , With LED Driver |
| massa | - |
| digunakan untuk | Industrial |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
