| Nomor Bagian | AM-1024600K5TMQW-01H |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1024×600 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | 8S3P |
| Antarmuka | LVDS |
| pabrikan | AMPIRE |
| ukuran layar | 7.0 inch |
| nomor piksel | 1024(RGB)×600 (WSVGA) 169PPI |
| area aktif (mm) | 153.6 × 90 (H×V) |
| area bezel (mm) | 156.2 × 92.6 (H×V) |
| pencahayaan | 1000 cd/m² (Typ.) |
| sudut pandang | 75/75/70/75 (Typ.)(CR≥10) |
| pemandangan bagus di | - |
| kedalaman warna | 16.7M |
| massa | TBD |
| tingkat penyegaran | 60Hz |
| jenis sinyal | LVDS (1 ch, 8-bit) , 20 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| nama model | AM-1024600K5TMQW-01H |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 165.5 × 104.44 × 9.46 (H×V×D) |
| perlakuan | Glare (Haze 0%), Hard coating |
| rasio kontras | 700 : 1 (Typ.) (TM) |
| tanggapan | 20/20 (Typ.)(Tr/Td) ms |
| mode kerja | TN, Normally White, Transmissive |
| lampu latar | 8S3P WLED , 50K hours , With LED Driver |
| digunakan untuk | Industrial Outdoor High Brightness |
| layar sentuh | Without |
