| Nomor Bagian | COM70T7M17ZLC |
| Merek | ORTUSTECH |
| Ukuran | 7.0 |
| Aplikasi | IA |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 530 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | ORTUSTECH |
| model panel | COM70T7M17ZLC |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 152.4×91.44 mm |
| garis besar | 165×105.8×3.65 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 530 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 40/60 (Max.)(Tr/Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 8S3PWLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit), 40 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | IA |
