| Nomor Bagian | WEA012864DWPP3N00001 |
| Merek | Winstar |
| Ukuran | 0.96 |
| Aplikasi | Instruments & Me |
| Resolusi | 128×64 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antarmuka | 4-wire |
| merek | Winstar |
| model | WEA012864DWPP3N00001 |
| ukuran diagonal | 0.96 inch |
| jenis | PM-OLED, OLED |
| format piksel | 128×64 149PPI |
| konfigurasi | Rectangle |
| daerah aktif | 21.74(H)×10.86(V) mm |
| garis besar redup. | 38(H)×28.5(V) ×4.37(D) mm |
| daerah bezel | 23.94(H)×12.06(V) mm |
| perlakuan | - |
| arah pandangan | Symmetry |
| waktu merespon | - |
| sudut pandang | - |
| Modus operasi | - |
| warna pendukung | Mono(White) |
| sumber cahaya | self |
| berat | - |
| dirancang untuk | Instruments & Meters |
| kecepatan bingkai | - |
| panel sentuh | Without |
| detail d-ic | COG Built-in SSD1306BZ |
| tipe antarmuka | 4-wire SPI, I²C , 8 pins PIN |
| Sumber Daya listrik | 3.3/5.0/7.5V (Typ.) |
| lingkungan | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
