| Nomor Bagian | TX31D32VM2AAA |
| Merek | KOE |
| Ukuran | 12.1 |
| Aplikasi | IA |
| Resolusi | 800×600 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | HITACHI |
| model panel | TX31D32VM2AAA |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 12.1 inch |
| resolusi | 800(RGB)×600 , SVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 246×184.5 mm |
| garis besar | 280×210×13.5 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit) |
| waktu merespon | 15/10 (Typ.)(Tr/Td) |
| sudut pandang | 65/65/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 20 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | IA |
| B121EW03 V0 | AUO | 12.1 | 1280×800 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| HT12X21-220 | HYDIS | 12.1 | 1024×768 |
| L5S30341P00 | SANYO | 12.1 | 800×600 |
| LQ121S1DG21 | SHARP | 12.1 | 800×600 |
| LTM12C268F | TOSHIBA | 12.1 | 800×600 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
| TM121XG-02L10 | SANYO | 12.1 | 1024×768 |
| TX31D32VM2AAA | KOE | 12.1 | 800×600 |
| TX31D37VM0CAA | KOE | 12.1 | 800×600 |
| AA084SB01 | Mitsubishi | 8.4 | 800×600 |
| AA084VB02 | Mitsubishi | 8.4 | 640×480 |
| AA10SA6C-ADDD | Mitsubishi | 10.4 | 800×600 |
| AA121SK26 | Mitsubishi | 12.1 | 800×600 |
| F-51430NFU-FW-AA | Kyocera | 9.4 | 640×480 |
| KCG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| M190EN01 V1 | AUO | 19.0 | 1280×1024 |
| NL6448BC26-11 | NLT | 8.4 | 640×480 |
| OEL9M0073-G-E | Other | 1.0 | 128×64 |
| TFD50W72MS | TOSHIBA | 5.0 |
