| Nomor Bagian | TX18D212VM0BAA |
| Merek | KOE |
| Ukuran | 7.0 |
| Aplikasi | Industrial Outdoor H |
| Resolusi | 1280×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | KOE |
| ukuran diagonal | 7.0 inch |
| format piksel | 1280(RGB)×768 [WXGA] 213PPI |
| daerah aktif | 152.448(H)×91.4688(V) mm |
| daerah bezel | 154.5(H)×93.5(V) mm |
| pencahayaan | 1000 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| warna pendukung | 16.7M 72% NTSC |
| berat | 212g (Typ.) |
| kecepatan bingkai | 60Hz |
| model | TX18D212VM0BAA |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 164.4(H)×105(V) ×13.5(D) mm |
| perlakuan | - |
| rasio kontras | 1000:1 (Typ.) (TM) |
| waktu merespon | 25 (Max.)(Tr+Tf) |
| Modus operasi | IPS, Normally Black, Transmissive |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| dirancang untuk | Industrial Outdoor High Brightness |
| panel sentuh | Without |
