| Nomor Bagian | LTP700WV-F01 |
| Merek | Samsung |
| Ukuran | 7.0 |
| Aplikasi | MP4 |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 300:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | SAMSUNG |
| model panel | LTP700WV-F01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800×480(RGB) , WVGA |
| mode tampilan | TN, Normally White, TMR |
| daerah aktif | 152.4×91.44 mm |
| garis besar | 163.2×104×3.6 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 300 : 1 (Typ.) |
| menampilkan warna | 16.7M (8-bit) |
| waktu merespon | 22.7 (Typ.)(Tr+Td) |
| sudut pandang | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 8S3PWLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 8-bit), 40 pins |
| tegangan masukan | 3.3V (Typ.)(VCC) |
| roh: | |
| aplikasi | MP4 |
