| Nomor Bagian | TV097QXM-NW0 |
| Merek | BOE |
| Ukuran | 9.7 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1536×2048 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | 6S6P |
| Antarmuka | MIPI |
| merek panel | BOE |
| model panel | TV097QXM-NW0 |
| ukuran panel | 9.7" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1536(RGB)×2048, QXGA, 264PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 147.456(W)×196.608(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 152.536(W)×206.548(H) ×4.5(D) mm |
| permukaan | - |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 1500:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Min.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 35 (Max.)(Tr+Td) |
| menampilkan warna | 16.7M 70% NTSC |
| jenis lampu | 6S6P WLED , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 135g (Max.) |
| aplikasi | Pad & Tablet |
| antarmuka sinyal | MIPI (4 data lanes) , 61 pins Connector |
| tegangan masukan | 1.8/5.5/-5.5V (Typ.)(VDDI/AVDD/AVEE) |
| lingkungan | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
