| Nomor Bagian | TMS150XG1-10TB Rev.E |
| Merek | Tianma |
| Ukuran | 15.0 |
| Aplikasi | DMPC |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | AVIC |
| model panel | TMS150XG1-10TB Rev.E |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 15.0 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 304.128×228.096 mm |
| garis besar | 326.5×253.5 mm |
| permukaan | Antiglare, Hard coating |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 600:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC), CIE193160% |
| waktu merespon | 8 (Typ.)(Tr+Td) |
| sudut pandang | 45/45/25/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 2 pcsCCFL |
| antarmuka sinyal | LVDS (1 ch, 8-bit) |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | DMPC |
