Samsung LTM230TT01 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com

LTM230TT01


Merek
Samsung
Ukuran
23.0
Aplikasi
DMPC
Resolusi
2048×1152
Komposisi
LCM
Kecerahan
300
CR
1000:1
Warna
16.7M
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
4523
Spesifikasi

Nomor Bagian LTM230TT01
MerekSamsung
Ukuran23.0
AplikasiDMPC
Resolusi2048×1152
KomposisiLCM
Kecerahan300
CR1000:1
Warna16.7M
Lampu latarCCFL
AntarmukaLVDS
merek panelSAMSUNG
model panelLTM230TT01
tipe panel a-Si TFT-LCD , LCM
ukuran panel23.0 inch
resolusi2048(RGB)×1152 , WDXGA
mode tampilanTN, Normally White, Transmissive
daerah aktif509.952×286.848 mm
garis besar531.4×310 mm
permukaanAntiglare (Haze 25%), Hard coating (3H)
kecerahan300 cd/m² (Typ.)
rasio kontras1000:1 (Typ.)
menampilkan warna16.7M (6-bit + Hi-FRC), CIE193172%
waktu merespon5 (Typ.)(Tr+Td)
sudut pandang80/80/80/80 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu4 pcsCCFLWithout Driver
antarmuka sinyalLVDS (2 ch, 8-bit), 30 pins
tegangan masukan5.0V (Typ.)
aplikasiDMPC
Model Keluarga
LTM230HL08 Samsung 23.0 1920×1080
LTM230HP07 Samsung 23.0 1920×1080
LTM230HT01 Samsung 23.0 1920×1080
LTM230HT02 Samsung 23.0 1920×1080
LTM230HT03 Samsung 23.0 1920×1080
LTM230HT05 Samsung 23.0 1920×1080
LTM230HT09 Samsung 23.0 1920×1080
LTM230HT10 Samsung 23.0 1920×1080
LTM230HU01 Samsung 23.0 1920×1080
LTM230TT01 Samsung 23.0 2048×1152
