| Nomor Bagian | HT15X23-100 |
| Merek | HYDIS |
| Ukuran | 15.0 |
| Aplikasi | DMPC |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 280 |
| CR | 450:1 |
| Warna | 16.2M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | BOE HYDIS |
| model panel | HT15X23-100 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 15.0 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mode tampilan | AFFS, Normally Black, Transmissive |
| daerah aktif | 304.128×228.096 mm |
| garis besar | 331.6×254.7 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 280 cd/m² (Typ.) |
| rasio kontras | 450:1 (Typ.) |
| menampilkan warna | 16.2M (6-bit + FRC), CIE193165% |
| waktu merespon | 40 (Typ.)(Tr+Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 4 pcsCCFLWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 20 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | DMPC |
