| Nomor Bagian | R156B48-167-0101 |
| Merek | No Brand |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 8S6P |
| Antarmuka | LVDS |
| merek panel | No Brand |
| model panel | R156B48-167-0101 1 Compatible |
| ukuran panel | 15.6" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 100PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 344.232(W)×193.536(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 359.3(W)×209.5(H) ×5.5(D) mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 200 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | 45/45/20/40 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 12 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 45% NTSC |
| jenis lampu | 8S6P WLED , 15K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| gaya bentuk | Wedge (PCBA Bent, T≥5.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | LVDS (1 ch, 6-bit) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B156HTN04.0 | AUO | 15.6 | 1920×1080 |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| LTN156AT01-B01 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-H01 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
| N156BGE-E42 | Innolux | 15.6 | 1366×768 |
| N156O6-L02 | Innolux | 15.6 | 1600×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
