| Nomor Bagian | TMS156WX1-02TC |
| Merek | Tianma |
| Ukuran | 15.6 |
| Aplikasi | DMPC |
| Resolusi | 1366×768 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antarmuka | LVDS |
| merek panel | AVIC |
| model panel | TMS156WX1-02TC |
| tipe panel | a-Si TFT-LCD , CELL |
| ukuran panel | 15.6 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 344.232×193.536 mm |
| permukaan | |
| rasio kontras | 500:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193160% |
| waktu merespon | 2/6 (Typ.)(Tr/Td) |
| sudut pandang | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 30 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
