| Nomor Bagian | QV101WUB-N80 |
| Merek | BOE |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1920×1200 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| pabrikan | BOE |
| ukuran layar | 10.1 inch |
| nomor piksel | 1920(RGB)×1200 (WUXGA) 224PPI |
| area aktif (mm) | 216.806 × 135.504 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 0 (cd/m²) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| ketebalan kaca | - |
| kedalaman warna | 16.7M 72% NTSC |
| massa | - |
| tingkat penyegaran | 60Hz |
| nama model | QV101WUB-N80 |
| tipe layar | CELL , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 221.81 × 145.5 (H×V×D) |
| perlakuan | Hard coating |
| rasio kontras | 900 : 1 (Typ.) (TM) |
| mode kerja | ADS, Normally Black, Transmissive |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| keterusan | 3.85% (Typ.)(with Polarizer) |
| lampu latar | No B/L |
| digunakan untuk | Industrial |
| layar sentuh | Without |
