| Nomor Bagian | P101DEA-AZ0 |
| Merek | Innolux |
| Ukuran | 10.1 |
| Aplikasi | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 4 |
| Antarmuka | MIPI |
| pabrikan | Innolux |
| nama model | P101DEA-AZ0 |
| ukuran layar | 10.1 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 800(RGB)×1280 (WXGA) 150PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 135.36 × 216.576 (H×V) |
| garis besar (mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Glare (Haze 0%), Hard coating |
| pencahayaan | 500 cd/m² (Typ.) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Min.)(CR≥10) |
| tanggapan | 35 (Max.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | AAS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 60% NTSC |
| lampu latar | 4 strings WLED , 15K hours , No Driver |
| massa | 175g (Max.) |
| digunakan untuk | Pad & Tablet |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | MIPI (4 data lanes) , Connector 40 pins |
| sumber tegangan | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| maks. peringkat | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
