| Nomor Bagian | LP101WX2-SLP1 |
| Merek | LG Display |
| Ukuran | 10.1 |
| Aplikasi | PAD |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | LG Display |
| model panel | LP101WX2-SLP1 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mode tampilan | IPS, Normally Black, Transmissive |
| daerah aktif | 216.96×135.6 mm |
| garis besar | 228.6×148.15×4.45 mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 500:1 (Min.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC) |
| waktu merespon | 35 (Typ.)(Tr/Td) |
| sudut pandang | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 40 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
