| Nomor Bagian | M236HVR01.0 CELL |
| Merek | AUO |
| Ukuran | 23.6 |
| Aplikasi | Desktop Monitor Gami |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| merek panel | AUO |
| ukuran panel | 23.6" |
| resolusi | 1920(RGB)×1080, FHD, 93PPI |
| area tampilan | 521.395(W)×293.285(H) mm |
| ukuran garis besar | 532.995(W)×305.185(H) ×1.11(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| kedalaman kaca | 0.40+0.40 mm |
| menampilkan warna | 16.7M 69% NTSC |
| frekuensi | 165Hz |
| berat | 530g (Typ.) |
| model panel | M236HVR01.0 CELL |
| tipe panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare (Haze 40%), Hard coating (3H) |
| rasio kontras | 3000:1 (Typ.) (TM) |
| mode tampilan | VA, Normally Black, Transmissive |
| waktu merespon | 20 (Typ.)(G to G) |
| keterusan | 3.22% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| layar sentuh | Without |
| aplikasi | Desktop Monitor Gaming |
