| Nomor Bagian | HR236WU1-100 |
| Merek | BOE |
| Ukuran | 23.6 |
| Aplikasi | DMPC |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | BOE |
| model panel | HR236WU1-100 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 23.6 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mode tampilan | ADS, Normally Black, Transmissive |
| daerah aktif | 521.28×293.22 mm |
| garis besar | 544.8×320.5×9.6 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC) |
| waktu merespon | 14 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 4 stringsWLEDWithout Driver |
| antarmuka sinyal | LVDS (2 ch, 8-bit), 30 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
| HR236WU1-100 | BOE | 23.6 | 1920×1080 |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| LTM236FL01 | Samsung | 23.6 | 3840×2160 |
| M236H1-L01 | Innolux | 23.6 | 1920×1080 |
| M236H1-P01 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-L31 | Innolux | 23.6 | 1920×1080 |
| V236BJ1-LE1 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P02 | Innolux | 23.6 | 1366×768 |
| CLAA185WA02 | CPT | 18.5 | 1366×768 |
| HT15X15-D01 | HYDIS | 15.0 | 1024×768 |
| LM220WE1-TLE2 | LG Display | 22.0 | 1680×1050 |
| LQ170E1LG11 | SHARP | 17.0 | 1280×1024 |
| LTM220MT05 | Samsung | 22.0 | 1680×1050 |
| M170E5-L09 | Innolux | 17.0 | 1280×1024 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M236MWF1 R0 | IVO | 23.6 | 1920×1080 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
