| Nomor Bagian | LTP280QV-E01 |
| Merek | Samsung |
| Ukuran | 2.8 |
| Aplikasi | MPH |
| Resolusi | 240×320 |
| Komposisi | LCM |
| Kecerahan | 110 |
| CR | 150:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | SAMSUNG |
| model panel | LTP280QV-E01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 2.8 inch |
| resolusi | 240(RGB)×320 , QVGA |
| mode tampilan | TN, Normally White, Transflective |
| daerah aktif | 43.2×57.6 mm |
| garis besar | 52.9×71.7×4.75 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 110 cd/m² (Typ.) |
| rasio kontras | 150:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| menampilkan warna | 262K (6-bit), CIE193130% |
| waktu merespon | 35 (Typ.)(Tr+Td) |
| sudut pandang | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 6S1PWLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit), 61 pins |
| tegangan masukan | 3.3/5.0/15/-10V (Typ.)(DVDD/AVDD/VON/VOFF) |
| aplikasi | MPH |
