| Nomor Bagian | PJ045IC-01F |
| Merek | Innolux |
| Ukuran | 4.5 |
| Aplikasi | MPH |
| Resolusi | 720×1280 |
| Komposisi | LCM |
| Kecerahan | 380 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | CHIMEI INNOLUX |
| model panel | PJ045IC-01F |
| tipe panel | LTPS TFT-LCD , LCM |
| ukuran panel | 4.5 inch |
| resolusi | 720(RGB)×1280 , WXGA |
| mode tampilan | IPS, Normally Black, Transmissive |
| daerah aktif | 55.512×98.688 mm |
| garis besar | 60.04×108.72 mm |
| permukaan | |
| kecerahan | 380 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193170% |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 5S2PWLEDWithout Driver |
| antarmuka sinyal | MIPI (4 data lanes), 30 pins |
| tegangan masukan | 1.8/2.8V (Typ.)(VDDIO/VCI) |
| aplikasi | MPH |
