| Nomor Bagian | LTM238HP01 |
| Merek | SAMSUNG |
| Ukuran | 23.8 |
| Aplikasi | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | SAMSUNG |
| nama model | LTM238HP01 |
| ukuran layar | 23.8 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 1920(RGB)×1080 (FHD) 92PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 527.04 × 296.46 (H×V) |
| garis besar (mm) | - |
| pencahayaan | - |
| rasio kontras | 3000 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tanggapan | 14 (Typ.)(G to G) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | PVA, Normally Black, Transmissive |
| kedalaman warna | 16.7M 72% NTSC |
| lampu latar | WLED |
| massa | - |
| digunakan untuk | Desktop Monitor |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (2 ch, 8-bit) , 30 pins Connector |
| sumber tegangan | 5.0V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
