| Nomor Bagian | LTL106AL01-002 |
| Merek | Samsung |
| Ukuran | 10.6 |
| Aplikasi | PAD |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | SAMSUNG |
| model panel | LTL106AL01-002 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.6 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mode tampilan | PLS, Normally Black, Transmissive |
| daerah aktif | 234.72×132.03 mm |
| garis besar | 246.52×149.02×5.2 mm |
| permukaan | Glare (Haze 0%), Hard coating (2H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193150% |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 30 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
