| Nomor Bagian | LTL101DL03-T01 |
| Merek | Samsung |
| Ukuran | 10.1 |
| Aplikasi | PAD |
| Resolusi | 2560×1600 |
| Komposisi | LCM |
| Kecerahan | 370 |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | SAMSUNG |
| model panel | LTL101DL03-T01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.1 inch |
| resolusi | 2560RG(BW)×1600 , WQXGA |
| mode tampilan | PLS, Normally Black, Transmissive |
| daerah aktif | 216.576×135.36 mm |
| garis besar | 232.22×156.92×5.2 mm |
| permukaan | Glare (Haze 0%), Hard coating (2H) |
| kecerahan | 370 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.2M (6-bit + FRC) |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 7S6PWLEDEmbedded (LED Driver) |
| antarmuka sinyal | eDP (4 Lanes), 45 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
