LM240WU8-SLA3

LM240WU8-SLA3
LM240WU8-SLA3
LM240WU8-SLA3 thumb LM240WU8-SLA3 thumb
Merek
LG Display
Ukuran
24.0
Aplikasi
DMPC
Resolusi
1920×1200
Komposisi
LCM
Kecerahan
350
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
54
Spesifikasi

Nomor Bagian LM240WU8-SLA3
MerekLG Display
Ukuran24.0
AplikasiDMPC
Resolusi1920×1200
KomposisiLCM
Kecerahan350
CR1000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelLG Display
model panelLM240WU8-SLA3
tipe panel a-Si TFT-LCD , LCM
ukuran panel24.0 inch
resolusi1920(RGB)×1200 , WUXGA
mode tampilane-IPS, Normally Black, Transmissive
daerah aktif518.4×324 mm
garis besar546.4×352×15 mm
permukaanAntiglare, Hard coating (3H)
kecerahan350 cd/m² (Typ.)
rasio kontras1000:1 (Typ.)
menampilkan warna16.7M (6-bit + Hi-FRC), CIE193172%
waktu merespon14 (Typ.)(G to G)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu4 stringsWLEDWithout Driver
antarmuka sinyalLVDS (2 ch, 8-bit), 30 pins
tegangan masukan12.0V (Typ.)
aplikasiDMPC
