LG Display LM215WF4-TLG1 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com

LM215WF4-TLG1


Merek
LG Display
Ukuran
21.5
Aplikasi
DMPC
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
250
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
49306
Spesifikasi

Nomor Bagian LM215WF4-TLG1
MerekLG Display
Ukuran21.5
AplikasiDMPC
Resolusi1920×1080
KomposisiLCM
Kecerahan250
CR1000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelLG Display
model panelLM215WF4-TLG1
tipe panel a-Si TFT-LCD , LCM
ukuran panel21.5 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanTN, Normally White, Transmissive
daerah aktif476.064×267.786 mm
garis besar495.6×292.2×10.7 mm
permukaanAntiglare, Hard coating (3H)
kecerahan250 cd/m² (Typ.)
rasio kontras1000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon1.3/3.7 (Typ.)(Tr/Td)
sudut pandang85/85/75/85 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu14S2PWLEDWithout Driver
antarmuka sinyalLVDS (2 ch, 8-bit), 30 pins
tegangan masukan5.0V (Typ.)
aplikasiDMPC
