MT190AW02 V.W

MT190AW02 V.W
MT190AW02 V.W
MT190AW02 V.W
MT190AW02 V.W thumb MT190AW02 V.W thumb MT190AW02 V.W thumb
Merek
Innolux
Ukuran
19.0
Aplikasi
DMPC
Resolusi
1440×900
Komposisi
LCM
Kecerahan
250
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
225
Spesifikasi

Nomor Bagian MT190AW02 V.W
MerekInnolux
Ukuran19.0
AplikasiDMPC
Resolusi1440×900
KomposisiLCM
Kecerahan250
CR1000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
merek panelINNOLUX
model panelMT190AW02 V.W
tipe panel a-Si TFT-LCD , LCM
ukuran panel19.0 inch
resolusi1440(RGB)×900 , WXGA+
mode tampilanTN, Normally White, Transmissive
daerah aktif408.24×255.15 mm
garis besar428×278 mm
permukaanAntiglare (Haze 25%), Hard coating (3H)
kecerahan250 cd/m² (Typ.)
rasio kontras1000:1 (Typ.)
menampilkan warna16.7M (6-bit + Hi-FRC), CIE193168%
waktu merespon1.5/3.5 (Typ.)(Tr/Td)
sudut pandang85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu5 stringsWLEDWithout Driver
antarmuka sinyalLVDS (2 ch, 8-bit), 30 pins
tegangan masukan5.0V (Typ.)
aplikasiDMPC
Model Keluarga
HSD190MEN4-A03 HannStar 19.0 1280×1024
MT190AW01 V.5 Innolux 19.0 1440×900
MT190AW01 V.7 Innolux 19.0 1440×900
MT190AW01 V.C Innolux 19.0 1440×900
MT190AW02 V.0 Innolux 19.0 1440×900
MT190AW02 V.4 Innolux 19.0 1440×900
MT190AW02 V.A Innolux 19.0 1440×900
MT190AW02 V.V Innolux 19.0 1440×900
MT190AW02 V.W Innolux 19.0 1440×900
MT190AW02 V.Y Innolux 19.0 1440×900
