| Nomor Bagian | LD420WUB-SCG1 |
| Merek | LG Display |
| Ukuran | 42 |
| Aplikasi | PID |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 1200:1 |
| Warna | 16.7M/1.06B |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | LG Display |
| model panel | LD420WUB-SCG1 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 42 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mode tampilan | S-IPS, Normally Black, Transmissive |
| daerah aktif | 930.24×523.26 mm |
| garis besar | 956.4×549.4×54.5 mm, Videowall Seam 26.2 mm |
| permukaan | Antiglare (Haze 10%), Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 1200:1 (Typ.) |
| menampilkan warna | 16.7M/1.06B (8-bit / 8-bit + FRC) |
| waktu merespon | 10 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | CCFLEmbedded (Inverter) |
| antarmuka sinyal | LVDS (2 ch, 8/10-bit), 51 pins |
| tegangan masukan | 12.0V (Typ.) |
| aplikasi | PID |
