LD420WUB-SCC1

LD420WUB-SCC1
LD420WUB-SCC1 thumb
Merek
LG Display
Ukuran
42
Aplikasi
PID
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
1000
CR
1200:1
Warna
16.7M/1.06B
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
19708
Spesifikasi

Nomor Bagian LD420WUB-SCC1
MerekLG Display
Ukuran42
AplikasiPID
Resolusi1920×1080
KomposisiLCM
Kecerahan1000
CR1200:1
Warna16.7M/1.06B
Lampu latarCCFL
AntarmukaLVDS
merek panelLG Display
model panelLD420WUB-SCC1
tipe panel a-Si TFT-LCD , LCM
ukuran panel42 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanS-IPS, Normally Black, Transmissive
daerah aktif930.24×523.26 mm
garis besar956.4×549.4×54.5 mm, Videowall Seam 26.2 mm
permukaanAntiglare (Haze 10%), Hard coating (3H)
kecerahan1000 cd/m² (Typ.)
rasio kontras1200:1 (Typ.)
menampilkan warna16.7M/1.06B (8-bit / 8-bit + Dithering)
waktu merespon9 (Typ.)(G to G)
sudut pandang89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampuCCFLEmbedded (Inverter)
antarmuka sinyalLVDS (2 ch, 8/10-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiPID
