| Nomor Bagian | HX104X02-100 |
| Merek | HYDIS |
| Ukuran | 10.4 |
| Aplikasi | PAD |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 340 |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | HYDIS |
| model panel | HX104X02-100 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.4 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mode tampilan | AFFS+, Normally Black, Transmissive |
| daerah aktif | 210.4×157.8 mm |
| garis besar | 238.6×173.2×6.8 mm |
| permukaan | Antiglare, Antireflection |
| kecerahan | 340 cd/m² (Typ.) |
| rasio kontras | 600:1 (Typ.) |
| menampilkan warna | 262K (6-bit), CIE193140% |
| waktu merespon | 36 (Typ.)(Tr+Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 7S6PWLEDEmbedded (LED Driver) |
| antarmuka sinyal | LVDS (1 ch, 6-bit), 30 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
