HV121WX5-113

HV121WX5-113
HV121WX5-113
HV121WX5-113
HV121WX5-113 thumb HV121WX5-113 thumb HV121WX5-113 thumb
Merek
HYDIS
Ukuran
12.1
Aplikasi
PAD
Resolusi
1280×800
Komposisi
LCM
Kecerahan
220
CR
500:1
Warna
262K
Lampu latar
WLED
Antarmuka
LVDS
In Stock
1360
Spesifikasi

Nomor Bagian HV121WX5-113
MerekHYDIS
Ukuran12.1
AplikasiPAD
Resolusi1280×800
KomposisiLCM
Kecerahan220
CR500:1
Warna262K
Lampu latarWLED
AntarmukaLVDS
merek panelHYDIS
model panelHV121WX5-113 3 Compatible model
tipe panel a-Si TFT-LCD , LCM
ukuran panel12.1 inch
resolusi1280(RGB)×800 , WXGA
mode tampilanAFFS, Normally Black, Transmissive
daerah aktif261.12×163.2 mm
garis besar276.8×180×6.8 mm
permukaanAntireflection
kecerahan220 cd/m² (Typ.)
rasio kontras500:1 (Typ.)
menampilkan warna262K (6-bit)
waktu merespon30 (Typ.)(Tr+Td)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu12S4PWLEDEmbedded (LED Driver)
antarmuka sinyalLVDS (1 ch, 6-bit), 40 pins
tegangan masukan3.3V (Typ.)
aplikasiPAD
Model Keluarga
HV121WX4-110 HYDIS 12.1 1280×800
HV121WX4-120 HYDIS 12.1 1280×800
HV121WX5-110 HYDIS 12.1 1280×800
HV121WX5-111 HYDIS 12.1 1280×800
HV121WX5-113 HYDIS 12.1 1280×800
HV121WX5-114 HYDIS 12.1 1280×800
HV121WX5-120 HYDIS 12.1 1280×800
HV121WX5-121 HYDIS 12.1 1280×800
HV121WX6-110 HYDIS 12.1 1280×800
HV121WX6-111 HYDIS 12.1 1280×800
