LG Display LP079X01-SMA1 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com

LP079X01-SMA1


Merek
LG Display
Ukuran
7.9
Aplikasi
PAD
Resolusi
768×1024
Komposisi
LCM
Kecerahan
425
CR
900:1
Warna
262K
Lampu latar
WLED
Antarmuka
MIPI
In Stock
6103
Spesifikasi

Nomor Bagian LP079X01-SMA1
MerekLG Display
Ukuran7.9
AplikasiPAD
Resolusi768×1024
KomposisiLCM
Kecerahan425
CR900:1
Warna262K
Lampu latarWLED
AntarmukaMIPI
merek panelLG Display
model panelLP079X01-SMA1
tipe panel a-Si TFT-LCD , LCM
ukuran panel7.9 inch
resolusi768(RGB)×1024 , XGA
mode tampilanAH-IPS, Normally Black, Transmissive
daerah aktif119.808×159.744 mm
garis besar129×171.07×4.81 mm
permukaanGlare (Haze 0%), Hard coating
kecerahan425 cd/m² (Typ.)
rasio kontras900:1 (Typ.)
menampilkan warna262K (6-bit)
waktu merespon17 (Typ.)(Tr+Td)
sudut pandang85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu6 stringsWLEDWithout Driver
antarmuka sinyalMIPI (4 data lanes), 32 pins
tegangan masukan3.6V (Typ.)
aplikasiPAD
Model Keluarga
B080XAN01.0 AUO 7.9 768×1024
B080XAN02.0 AUO 7.9 768×1024
LP079QX1-SP0V LG Display 7.9 1536×2048
LP079X01-SMA1 LG Display 7.9 768×1024
LP079X01-SMA2 LG Display 7.9 768×1024
LP079X01-SMA7 LG Display 7.9 768×1024
LP079X01-SMAV LG Display 7.9 768×1024
PA079DS4 E Ink 7.9 480×234
PA080XS2 E Ink 7.9 480×468
