| Nomor Bagian | HSD140PNW1-B00 |
| Merek | HannStar |
| Ukuran | 14.0 |
| Aplikasi | NBPC |
| Resolusi | 1600×900 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | HannStar |
| model panel | HSD140PNW1-B00 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 14.0 inch |
| resolusi | 1600(RGB)×900 , HD+ |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 309.6×174.15 mm |
| garis besar | 320.4×205.1×3 mm |
| gaya bentuk | Slim (PCBA Flat, Depth ≤3.2mm) |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 300:1 (Typ.) |
| menampilkan warna | 262K (6-bit), CIE193160% |
| waktu merespon | 4/12 (Typ.)(Tr/Td) |
| sudut pandang | 40/40/15/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | eDP (2 Lanes), 30 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | NBPC |
| B140HTN01.3 | AUO | 14.0 | 1920×1080 |
| B140RW01 V2 | AUO | 14.0 | 1600×900 |
| BT140GW01 V.5 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.2 | Innolux | 14.0 | 1366×768 |
| CLAA140UA01 CN | CPT | 14.0 | 1600×900 |
| CLAA140WA01 | CPT | 14.0 | 1280×768 |
| HSD140PHW2-A00 | HannStar | 14.0 | 1366×768 |
| HSD140PNW1-B00 | HannStar | 14.0 | 1600×900 |
| LP140WH1-TLD1 | LG Display | 14.0 | 1366×768 |
| N140BGE-L33 | Innolux | 14.0 | 1366×768 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| LP150X08-TLAC | LG Display | 15.0 | 1024×768 |
| LT121S1-153 | Samsung | 12.1 | 800×600 |
| LTD111EWAX | TOSHIBA | 11.1 | 1366×768 |
| LTN133AT13-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT25-501 | Samsung | 13.3 | 1366×768 |
| LTN141AT16-002 | Samsung | 14.1 | 1280×800 |
| LTN141P4-L02 | Samsung | 14.1 | 1400×1050 |
| LTN154CT04-D01 | Samsung | 15.4 | 1920×1200 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
