| Nomor Bagian | HSD070PFW3-D00 |
| Merek | HannStar |
| Ukuran | 7.0 |
| Aplikasi | MP4 |
| Resolusi | 1024×600 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | HannStar |
| model panel | HSD070PFW3-D00 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 1024(RGB)×600 , WSVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 153.6×90 mm |
| garis besar | 167.25×104.65×3 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.2M (6-bit + FRC), CIE193150% |
| waktu merespon | 4/12 (Typ.)(Tr/Td) |
| sudut pandang | 80/70/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 4S5PWLEDWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 31 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | MP4 |
