| Nomor Bagian | A070VW08 V0 |
| Merek | AUO |
| Ukuran | 7.0 |
| Aplikasi | MP4 |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | AUO |
| model panel | A070VW08 V0 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800×480(RGB) , WVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 152.4×91.44 mm |
| garis besar | 164×103×5.3 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193150% |
| waktu merespon | 12/18 (Typ.)(Tr/Td) |
| sudut pandang | 80/80/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 3S7PWLEDWithout Driver |
| antarmuka sinyal | TTL (1 ch, 8-bit) + SPI, 60 pins |
| tegangan masukan | 3.3/5/-5/14/-14V (Typ.)(VCC/VDPA/VDNA/VGH/VGL) |
| aplikasi | MP4 |
