| Nomor Bagian | CLAA070LC0ACW |
| Merek | CPT |
| Ukuran | 7.0 |
| Aplikasi | MP4 |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 220 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | CPT |
| model panel | CLAA070LC0ACW |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 152.4×91.44 mm |
| garis besar | 165×104×5.3 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 220 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | TTL (1 ch, 6-bit), 40 pins |
| tegangan masukan | 3.3V (Typ.)(VCC) |
| roh: | |
| aplikasi | MP4 |
