| Nomor Bagian | G101EAN02.2 |
| Merek | AUO |
| Ukuran | 10.1 |
| Aplikasi | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | AUO |
| model panel | G101EAN02.2 |
| ukuran panel | 10.1" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1280(RGB)×800, WXGA, 149PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 216.96(W)×135.6(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 227.91(W)×148(H) ×7.75(D) mm |
| permukaan | Hard coating |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| mode tampilan | AHVA, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 29 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 50% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 290g (Max.) |
| aplikasi | Industrial |
| antarmuka sinyal | LVDS (1 ch, 8-bit) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
