| Nomor Bagian | DMC-16117A |
| Merek | Kyocera |
| Ukuran | 2.4 |
| Aplikasi | |
| Resolusi | 16×1 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | Monochrome |
| Lampu latar | No B/L |
| Antarmuka | CPU |
| merek panel | OPTREX |
| model panel | DMC-16117A |
| tipe panel | TN-LCD , LCM |
| ukuran panel | 2.4 inch |
| format tampilan | 16 characters × 1 lines |
| mode tampilan | TN, Reflective |
| menampilkan font | 5×8 dots |
| ukuran karakter | 3.2×5.95 mm |
| nada karakter | 3.75×5.95 mm |
| daerah aktif | 59.4×5.95 mm |
| daerah bezel | 64.5×13.0 mm |
| garis besar | 80×36×10 mm |
| kecerahan | |
| rasio kontras | 3.5:1 (Typ.)(Reflective) |
| menampilkan warna | Monochrome |
| waktu merespon | 180/130 (Typ.)(Tr/Td) |
| jenis lampu | No B/L |
| antarmuka sinyal | 8-bit parallel, 14 pins |
| tegangan masukan | 5.0V (Typ.) |
