| Nomor Bagian | DLC0270CUOF |
| Merek | Other |
| Ukuran | 2.7 |
| Aplikasi | |
| Resolusi | 256×64 |
| Komposisi | OLED |
| Kecerahan | 100 |
| CR | 10000:1 |
| Warna | Mono(White) |
| Lampu latar | self |
| Antarmuka | CPU/SPI |
| merek panel | DLC |
| model panel | DLC0270CUOF 1 Compatible model |
| tipe panel | PM-OLED , OLED |
| ukuran panel | 2.7 inch |
| resolusi | 256×64 |
| daerah aktif | 66.53×16.61 mm |
| garis besar | 82×25.5×1.6 mm |
| permukaan | |
| kecerahan | 100 cd/m² (Typ.) |
| rasio kontras | 10000 : 1 (Min.) |
| menampilkan warna | Mono(White) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 100Hz |
| ic pengemudi | COF Built-in SSD1322UR1 |
| antarmuka sinyal | 8-bit 6800/8080 parallel, 3/4-wire SPI, 30 pins |
