| Nomor Bagian | DLC0283FZG-7 |
| Merek | Other |
| Ukuran | 2.8 |
| Aplikasi | MPH |
| Resolusi | 240×320 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | CPU/RGB |
| merek panel | DLC |
| model panel | DLC0283FZG-7 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 2.8 inch |
| resolusi | 240(RGB)×320 , QVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 43.2×57.6 mm |
| garis besar | 50×70 mm |
| permukaan | |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) |
| menampilkan warna | 262K , CIE193150% |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 5S1PWLEDWithout Driver |
| antarmuka sinyal | CPU/RGB, 39 pins |
| tegangan masukan | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aplikasi | MPH |
