| Nomor Bagian | DLC0350CZG-T-2 |
| Merek | Other |
| Ukuran | 3.5 |
| Aplikasi | DSC |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 320 |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | Parallel/Serial |
| merek panel | DLC |
| model panel | DLC0350CZG-T-2 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 3.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 70.08×52.56 mm |
| garis besar | 76.9×64 mm |
| permukaan | |
| kecerahan | 320 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193150% |
| waktu merespon | 10/15 (Typ.)(Tr/Td) |
| sudut pandang | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 6S1PWLEDWithout Driver |
| antarmuka sinyal | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| tegangan masukan | 3.3V (Typ.)(VDDIO/VCI) |
| aplikasi | DSC |
