| Nomor Bagian | DLC0350CZG-T |
| Merek | Other |
| Ukuran | 3.5 |
| Aplikasi | DSC |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 260 |
| CR | 370:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | Parallel/Serial |
| merek panel | DLC |
| model panel | DLC0350CZG-T |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 3.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 70.08×53.56 mm |
| garis besar | 76.9×64×4.45 mm |
| permukaan | |
| kecerahan | 260 cd/m² (Typ.) |
| rasio kontras | 370:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193155% |
| waktu merespon | 10/15 (Typ.)(Tr/Td) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 6S1PWLEDWithout Driver |
| antarmuka sinyal | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | DSC |
| 35HVF0H | SII | 3.5 | 320×480 |
| DLC0350AMG-4 | Other | 3.5 | 320×240 |
| DLC0350BMG-1 | Other | 3.5 | 240×320 |
| DLC0350CZG-T | Other | 3.5 | 320×240 |
| DLC0350CZG-T-2 | Other | 3.5 | 320×240 |
| DLC0350FVG-5 | Other | 3.5 | 320×240 |
| DLC0350SZG | Other | 3.5 | 480×640 |
| DLC0350TZG | Other | 3.5 | 240×320 |
| LQ035LC111 | Innolux | 3.5 | 320×240 |
| LQ035Q7DH06 | SHARP | 3.5 | 240×320 |
| 990000006 | TPO | 3.0 | 320×240 |
| A018AN03 V1 | AUO | 1.8 | 280×220 |
| A027DN01 VB | AUO | 2.7 | 320×240 |
| A027DTN01.3 | AUO | 2.7 | 320×240 |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| LS020A8DX02 | SHARP | 2.0 | 320×240 |
| PD024OX4 | E Ink | 2.4 | 480×234 |
| TD025THEA3 | TPO | 2.5 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
