| Nomor Bagian | CLAA069LA0ACW |
| Merek | CPT |
| Ukuran | 7.0 |
| Aplikasi | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | CPT |
| model panel | CLAA069LA0ACW |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 156.6×81.6 mm |
| garis besar | 167×93.12×6.77 mm |
| permukaan | Antiglare |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) |
| menampilkan warna | 262K (6-bit), CIE193170% |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 6S4PWLEDWithout Driver |
| antarmuka sinyal | TTL (1 ch, 6-bit), 60 pins |
| tegangan masukan | 3.3/9.2/18/-6V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikasi | CNS |
