| Nomor Bagian | AC070MD01 |
| Merek | Mitsubishi |
| Ukuran | 7.0 |
| Aplikasi | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 600 |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | Mitsubishi |
| model panel | AC070MD01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 152.4×91.44 mm |
| garis besar | 165×104×7.55 mm |
| permukaan | Antiglare, Reflection 4.0% (Typ.) |
| kecerahan | 600 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 262K (6-bit), CIE193150% |
| waktu merespon | 40 (Max.)(Tr+Td) |
| sudut pandang | 55/55/60/30 (Min.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antarmuka sinyal | TTL (1 ch, 6-bit), 60 pins |
| tegangan masukan | 3.3/13.0/18.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikasi | CNS |
| A070PAN01.0 | AUO | 7.0 | 900×1440 |
| AC070MD01 | Mitsubishi | 7.0 | 800×480 |
| C070VTN01.0 | AUO | 7.0 | 800×480 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| CLAA070WA01 | CPT | 7.0 | 480×234 |
| G070Y1-T01 | Innolux | 7.0 | 800×480 |
| LA070WV6-SL01 | LG Display | 7.0 | 800×480 |
| LB070WV7-TL01 | LG Display | 7.0 | 800×480 |
| LQ070T5DG30 | SHARP | 7.0 | |
| TCG070WVLBA-A00 | Kyocera | 7.0 | 800×480 |
| AV080WSM-NW3 | BOE | 8.0 | 1024×600 |
| C102EVN01.0 | AUO | 10.2 | 1280×720 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA102NA01CW | CPT | 10.2 | 1024×600 |
| LQ049B5DG04 | SHARP | 4.9 | 320×96 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ070Y5DG36 | SHARP | 7.0 | 800×480 |
| LTA065B0F0F | TOSHIBA | 6.5 | 800×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
