| Nomor Bagian | LQ080Y5DG03 |
| Merek | SHARP |
| Ukuran | 8.0 |
| Aplikasi | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 540 |
| CR | |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | SHARP |
| model panel | LQ080Y5DG03 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 8.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 174×104.4 mm |
| garis besar | 190×120 mm |
| permukaan | |
| kecerahan | 540 cd/m² (Typ.) |
| rasio kontras | |
| menampilkan warna | 262K (6-bit), CIE193165% |
| waktu merespon | |
| sudut pandang | |
| jenis lampu | WLED |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit) |
| aplikasi | CNS |
