| Nomor Bagian | AM-800480RBTMQW-TA1H-A |
| Merek | AMPIRE |
| Ukuran | 7.0 |
| Aplikasi | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | 3S10P |
| Antarmuka | LVDS |
| merek panel | AMPIRE |
| model panel | AM-800480RBTMQW-TA1H-A |
| ukuran panel | 7.0" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 800(RGB)×480, WVGA, 133PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 152.4(W)×91.44(H) mm |
| bukaan bezel | 155.3(W)×94.3(H) mm |
| ukuran garis besar | 165(W)×104.44(H) ×8.06(D) mm |
| permukaan | - |
| kecerahan | 255 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) (TM) |
| sudut pandang | 70/70/70/60 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | 6 o'clock |
| waktu merespon | 5/11 (Typ.)(Tr/Td) |
| menampilkan warna | 262K |
| jenis lampu | 3S10P WLED , 40K hours , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | PCAP |
| berat panel | TBD |
| aplikasi | Industrial |
| antarmuka sinyal | LVDS (1 ch, 6-bit) , 20 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
